Lab, SIVB 207 & 209 inside. |
& 207 outside Vehicle Check-out Lab. |
SIVB 206 removal from tower 2, VCL. |
SIVB 206 is placed onto transporter, VCL. |
SIVB 504 in tower 1, South bay of the Vehicle Check-out Lab. |
vertical and horizontal long term storage covers during preliminary functional tests. |
Development building. |
Lab. |
SIVB 205 (horizontal), 206 (on bird cage) & 207 in North tower of the A45 Vehicle Check-out Lab. |
Applying aluminized mylar to forward dome of SIVB 209 in Vehicle
Check-out Lab, tower 1. |
prepared for painting in the A45 building. |
|
SIVB 205 in foreground with 207 on "bird cage" and 206 in tower 2 behind in North bay of VCL. |
SIVB 208 (horizontal) & 209 in South tower of the A45 Vehicle Check-out Lab. |
SIVB 209 (BG) & 208
(FG) in storage in the Engineering Development building. |
Vertical storage cover being lowered onto SIVB 211 prior to being placed in tower 2 of VCL. |
SIVB 211 in Vehicle Check-out Lab tower 2 as storage covers are being applied. |
Lowering the J2 engine from SIVB 207 to allow installation of the Augmented Spard Assembly in the A45 Vehicle Check-out Lab. |
SIVB 207 (FG) & 208 in the A-45 Vehicle
check-out lab. |
Consoles manned inside
the Alpha blockhouse during test of the DA-103 Common Bulkhead Specimen. |
SIVB 209 entering the
door of the Engineering Development building. |
SIVB 209 entering the
door of the Engineering Development building. |
SIVB 505 enroute to
Mather AFB with Beta test stands in distance. |
