Beta I stand with SIVB 504 installed. View looking North. |
Beta I stand with new
SIVB 503 installed. View looking North. |
View past security gate of Beta I stand with new SIVB 503 stage installed. |
Section of damaged deck is lowered from Beta III. |
Men examining cabling from Beta III stand to see if it can be reused for
stand refurbishment. |
SIVB 505 is lifted onto
Beta I stand as 504 waits in foreground. |
SIVB 504 being hoisted
into Beta I stand, 209 in foreground. |
Beta I as SIVB 507 is removed. |
Beta I as SIVB 507 is removed. |
SIVB 506 being raised onto Beta III stand. |
SIVB 505 being lowered from Beta III onto "bird cage" stand. |
SIVB 507 being lowered from Beta I onto "bird cage" stand. |
SIVB 505 is removed from Beta III stand. |
Beta I stand during SIVB 208 acceptance firing.
View looking West. |
Beta I stand during 208 acceptance test firing. |
The Alpha Test Stand with the 8 foot insulated tank. |
Externally insulated 8 foot tank being placed in test structure at Alpha 1 test stand. |
View from the Alpha 1 test stand of the 8 foot insulated tank. |
helium sphere from Kappa test stand cell "C". |
SIVB 208 test firing. |
Beta III test stand top deck after SIVB 503 explosion. |
Beta III test stand top deck after 503 explosion. |
Beta III test stand. |
Ruined Beta III test stand engine deck & SIVB 503 J2 engine. |
